Sant C.I. Butterfly Valve Wafer Type (Lever Operated) BFX (A)

Sant C.I. Butterfly Valve Wafer Type (Lever Operated) BFX (A)

Sant Valves: Leading Industrial Valves for Quality & Performance logo
Sant Valves: Leading Industrial Valves for Quality & Performance

Available Variants

Excluding GST and Shipping
Prices are indicative and may vary based on quantity and specifications

Product Description

Product Overview The Sant C.I. Butterfly Valve Wafer Type (Lever Operated) BFX (A) is a robust and reliable solution for flow control in various industrial applications. Engineered for durability and efficient operation, this valve features a replaceable EPDM lined seat and an SG Iron disc, ensuring excellent sealing and resistance to wear. Its cast iron body, manufactured to IS:210 FG 260 standards, provides a strong and stable structure, designed for seamless integration between ASME B 16.1 CI-125 flanges. With high body and seat test pressures, this valve guarantees dependable performance under demanding conditions.

Technical Specifications

  • Brand: SANT
  • Type of Pattern: Replaceable Seat & Disc
  • Pressure/Class/Rating: PN16
  • Body Material cum standard: Cast Iron to IS:210 FG 260
  • Type of Seat: EPDM Lining
  • Type of Disc: SG Iron
  • Stem: AISI-410
  • End Details: Suitable between Flanges ASME B 16.1 CI-125
  • Body Test Pressure: 2.4MPa Hyd.
  • Seat Test Pressure: 1.8MPa Hyd.

Industrial Applications

  • Water Treatment Plants
  • HVAC Systems
  • General Industrial Piping
  • Fire Protection Systems

Similar Products

Butterfly Valve CI PSS-100

Butterfly Valve CI PSS-100

Starting from
₹∞
This cast iron butterfly valve provides efficient flow control and shut-off in industrial applications. Its durable construction and simple operation make it a practical choice for various fluid handling needs. The valve's design allows for easy throttling and modulation of flow.
WhatsApp

BUTTERFLY VALVE WAFER TYPE (PN10)

Starting from
₹∞
  • Model No.: BFV-414
  • Product Name: Butterfly Valve
  • Body Material cum Standard: Cast Iron (IS210 Gr. FG200)
  • Product Description: Wafer Type
  • Type of Seat: Molded EPDM / NBR
  • Type of Disc: SG Iron/CF8/CF8M
  • Trim: Stem – 13% Cr.SS (ASTM A276 Gr. 410)
  • Packing: Plastic (PTFE/ Nylon)
  • End Details: Suitable for Insertion between BS4504 PN10/PN16; ASME B16.5 # 150 BS 10 Table D/E Flanges
  • Test Pressure: B.T.P. 15 bar Hyd., S.T.P. 11 Bar Hyd.
WhatsApp

CAST IRON DUAL PLATE CHECK VALVE

Starting from
₹∞
  • Model No.: DPCV-469
  • Product Standard: PN: 16
  • Body Material cum Standard: Cast Iron (BS: 1452 Gr220)
  • Product Description: Resilient Seated, Non Slam in Nature, Prevents Water hemorrhage
  • Door: SG Iron/ CF8
  • Bush: PTFE
  • Springs: SS 304 / 316/MS
  • End Details: Suitable for Insertions between PN10/PN16 CL -150/ BS: 10 Table E/F/H
  • Test Pressure: B.T.P. -24 bar Hyd., S.T.P. - 17.6 bar Hyd.
WhatsApp

CAST IRON GLOBE VALVE

Starting from
₹1,870
  • Model No.: GBV-426
  • Product Standard: BS 5152/Din 86251 | BS:EN 13789
  • Type of Pattern: Straight Pattern
  • Product Description: Bolted Bonnet, Outside Screw & Yoke type Rising Stem
  • Type of Seat & Disc: Renewable
  • Handwheel: Cast Iron as per IS 210 Gr. FG 200
  • Stud, Nut & Washer: Carbon steel as per IS 1367
  • End Details (default): Flange Ends as per DIN 2533 Raised Face PN16 Undrilled
  • Pressure Rating (default): Till 150mm Pn16
  • Hydraulic Test Pressure (default): Body 26 kg/cm², seat 17.3/kg/cm²
  • Working Pressure (default): Max. BOP 13 kg/cm² at 220ºC

Note: for 200mm

  • Pressure Rating (200mm): PN10
  • End Details (200mm): Flanged ends as per DIN 2533 Raised Face
  • Hydraulic Test Pressure (200mm): Body 17 kg/cm², seat 11.3/kg/cm²
  • Working Pressure (200mm): Max. BOP 8.5 kg/cm²
  • End Details (200mm, alternative): Flanged ends as per DIN 2532 Raised Face
