Sant C.I. Ball Valve CI 18

Name: Sant C.I. Ball Valve CI 18
SKU: sant-ci-ball-valve-ci-18
Price: 1296 INR
Availability: InStock

Sant Valves: Leading Industrial Valves for Quality & Performance

Available Variants

Quantity:

Item Notes (optional)

Excluding GST and Shipping
Prices are indicative and may vary based on quantity and specifications

Product Description

Product Overview The Sant Cast Iron Ball Valve CI 18 is a high-quality, three-piece design valve that meets the IS-9890-1981 Class-125 standard. It features a renewable Teflon seat and AISI 410 stem stainless steel, making it suitable for various industrial applications.

Technical Specifications

Brand: SANT
Product Standard: IS-9890-1981 Class-125
Body Material: Cast Iron IS 210 Gr. FG 220
Type of Seat: Renewable Teflon Seat
Trim: AISI 410 Stem Stainless Steel, AISI 304 Ball
Gland Packing: Teflon Rings
End Details: Flanges as per IS:3516-1966 Undrilled
Body Test Pressure: 21barg, 300Psig (Hyd.)
Seat Test Pressure: 220Psig (15.4barg) Hyd., 100Psig (6.9 bar) Air

Industrial Applications

Water
Oil
Gas
