Sant Cast Steel Globe Valve CS 1
Available Variants
Excluding GST and Shipping
Prices are indicative and may vary based on quantity and specifications
Product Description
Product Overview The Sant Cast Steel Globe Valve CS 1 is a high-quality valve designed for various industrial applications. It features a bolted bonnet, O/S & Yoke type rising stem, and a renewable seat and disc.
Technical Specifications
- Brand: SANT
- Product Standard: BS:EN-13709/BS: 5160 / DIN 2401
- Pressure/Class/Rating: PN-40
- Body Material: CCS (ASTM A-216 Gr. WCB)
- Type of Seat: Renewable Seat
- Type of Disc: Renewable Disc
- Trim: Stainless Steel AISI-410
- End Details: Flanges as per BS 4504 Part-1/DIN 2545 RF undrilled
- Body Test Pressure: 76barg (1100 Psig.) Hyd.
- Seat Test Pressure: 40barg (580 Psig.) Hyd.
Industrial Applications
- Oil and gas industry
- Chemical processing plants
- Power generation plants
- Water treatment facilities
