Sant Cast Steel Gate Valve CS 7
Available Variants
Excluding GST and Shipping
Prices are indicative and may vary based on quantity and specifications
Product Description
Product Overview The SANT Cast Steel Gate Valve CS 7 is a robust and reliable Class-150 gate valve engineered for demanding industrial applications. Conforming to international standards including BS:EN-10434, API-600, and BS:1414, this valve features a bolted bonnet, outside screw and yoke (O/S Yoke) rising stem design, and renewable seats for extended service life and ease of maintenance. Constructed from ASTM A-216 Gr. WCB cast carbon steel, it ensures exceptional durability and performance under pressure.
Technical Specifications
- Brand: SANT
- Product Standard: Conforming to BS:EN-10434/API-600/BS:1414
- Type of Pattern: Straight
- Pressure/Class/Rating: Class-150
- Body Material cum standard: CCS (ASTM A-216 Gr. WCB)
- Product Description: Bolted Bonnet O/S Yoke type Rising Stem
- Type of Seat: Renewable Seat
- Type of Wedge: Solid / Flexible
- Trim: SS AISI-410 with Aluminum Bronze Sleeve
- End Details: Flanges as per ASME B 16.5 Class 150 R.F., undrilled
- Body Test Pressure: 30barg Hyd. (435 Psig)
- Seat Test Pressure: 22barg (320Psig.) Hyd. 6.9barg AIR (100Psig.)
Industrial Applications
- Oil & Gas pipelines and processing facilities
- Power generation plants
- Chemical and petrochemical industries
- Water treatment and distribution systems
- General industrial process lines requiring reliable flow isolation
