Sant CI. Butterfly Valve Wafer Type (Gear Operated) BFX (G)

Name: Sant CI. Butterfly Valve Wafer Type (Gear Operated) BFX (G)
SKU: sant-ci-butterfly-valve-wafer
Price: 8594 INR
Availability: InStock

Sant Valves: Leading Industrial Valves for Quality & Performance

Available Variants

Quantity:

Item Notes (optional)

Excluding GST and Shipping
Prices are indicative and may vary based on quantity and specifications

Product Description

Product Overview The Sant Cast Iron Butterfly Valve is a high-quality, gear-operated valve designed for efficient flow control in various industrial applications.

Technical Specifications

Brand: SANT
Type of Pattern: Replaceable Seat & Disc
Pressure/Class/Rating: PN-16
Body Material: Cast Iron to IS:210 FG 260
Type of Seat: EPDM Lining
Type of Disc: SS 304
Stem: AISI 410
End Details: Suitable between Flanges ASME B 16.1 or Class -125
Body Test Pressure: 2.4MPa (Hyd.)
Seat Test Pressure: 1.8MPa (Hyd.)

Industrial Applications

Water supply systems
Industrial process control
Chemical processing
